产品名称：DALI 接口调光72W，小功率LED驱动电源
LED103 Constant voltage converter 100-240V AC
•

Highlights:
 Constant voltage 24V PWM Output
 DALI digital control input, dimming control LED modules
 1 addressable output channel
 Dimming range from 0-100%，LED start at 0.1% possible
 Suitable for DC supply
 Over temperature protection
 Safety class 2




Approved For Lamps: Low Power LED

Type LED103
Article Number                                      Art.No.653103
Technical data:
Parameter Min.* Nom.* Max. Unit
Input Voltage Range 90 120 240 Vac
Input Frequency 47 50-60 63 Hz
Input Current@120VAC - 620 - mA
Power Factor@120VAC - 0.95 -
Output Power(1 Channel Pout Total) 1 72 - W
Output Voltage - 24 Vdc
Output Current - 6000 - mA
Dimming Control (Dimmer) DALI
Case Temp. - - 80 ℃
Ambient Temp. -25 - 50 ℃
Protection                  Short Circuit Protection
                            Overload Protection
                          Over Heat Protection
*Valid at ambient temperature of 25℃
